Mersen ATQ1-1/2 - Midget Fuse 1A (500V, 10kA AIC)

Mersen ATQ1-1/2 is a low-voltage midget fuse from the Amp-Trap family, designed for circuit protection in industrial electrical systems. It features a 500V AC/DC voltage rating and 1A current rating, with a compact 1-1/2-inch length and 0.41-inch diameter cylindrical design. The single-barrel fuse meets CSA and UL safety standards, offering 10kA interrupting capacity at 500V for reliable short-circuit protection. Its robust construction makes it suitable for motor control circuits, transformers, and power distribution panels requiring precise overcurrent protection.

Key Features & Specifications

• Type: ATQ series midget fuse with single barrel construction
• Voltage Rating: 500V AC/DC
• Current Rating: 1A
• Dimensions: 1-1/2 in length x 0.41 in diameter
• Weight: 0.01 lb
• Standards: CSA, UL certified
• Applications: Motor controls, transformers, power distribution
• AIC rating: 10kA@500V
• Class Rating: Midget
• Barrels: 1
• Country of Origin: Mexico

Product Identification

• UPC: 782001902766
• GTIN: 00782001902766
