Mersen ATDR4-1/2 - Class CC Fuse 4A 600V (200kA AIC)

Mersen ATDR4-1/2 is a Class CC low-voltage current-limiting fuse designed for protecting control circuits, transformers, and semiconductors in industrial applications. It features a 600V AC voltage rating with a 4A current rating and provides 200kA interrupting capacity at 600V. The fuse construction utilizes a single-barrel design measuring 1-1/2 inches in length with 0.41-inch diameter, weighing 0.02 lb for compact installation. Certified to UL/CSA standards, this Amp-Trap 2000 series fuse ensures reliable protection in control panels, motor circuits, and power distribution systems where precise overcurrent protection is critical.

Key Features & Specifications

• Type: Class CC current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 4A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Control circuits, transformers, semiconductor protection
• AIC rating: 200kA @ 600V
• Class Rating: CC
• Barrels: 1
• Weight: 0.02 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001908560
• GTIN: 00782001908560
