Mersen ATDR2-1/2 - Class CC Fuse 2A 600V (200kA AIC Rating)

Mersen ATDR2-1/2 is a current-limiting, low-voltage fuse designed for comprehensive circuit protection in industrial applications, providing reliable overcurrent and short-circuit interruption. It features a 600V AC voltage rating with a 2A current rating and offers exceptional 200kA interrupting capacity at 600V AC. The fuse construction includes a single-barrel design with 0.41-inch diameter and 1-1/2-inch length, manufactured to Class CC specifications for consistent performance. This unit complies with UL/CSA certification standards, ensuring adherence to rigorous safety requirements. Typical applications include protection of control circuits, transformers, and motor controllers across various industrial environments.

Key Features & Specifications

• Type: Current-limiting low-voltage fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 2A
• Dimensions: 1-1/2 inch length, 0.41 inch diameter
• Standards: UL/CSA certified
• Applications: Control circuits, transformers, motor controllers
• AIC rating: 200kA@600V AC
• Class Rating: CC
• Barrels: 1
• Weight: 5 lb
• Family: Amp-Trap 2000
• Country of Origin: Mexico

Product Identification

• UPC: 782001900953
• GTIN: 00782001900953
