Mersen ATDR1-1/8 - Class CC Fuse 1A 600V (200kA AIC Rating)
Mersen ATDR1-1/8 - Class CC Fuse 1A 600V (200kA AIC Rating)
Mersen ATDR1-1/8 - Class CC Fuse 1A 600V (200kA AIC Rating)
Mersen ATDR1-1/8 - Class CC Fuse 1A 600V (200kA AIC Rating)

Mersen ATDR1-1/8 - Class CC Fuse 1A 600V (200kA AIC Rating)

Mersen
Price
Save $69.85
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Mersen ATDR1-1/8 is a low voltage current-limiting fuse designed for protecting sensitive electrical components and control circuits from short-circuit and overload conditions. It features a 600V AC voltage rating with a 1A current rating and provides high interrupting capacity up to 200kA at 600V AC. The fuse construction includes a single-barrel design with 0.41-inch diameter and 1-1/2-inch length, weighing 0.02 lb for compact installation. Certified to UL/CSA standards, this Class CC fuse meets rigorous safety requirements for industrial applications. Typical uses include protection of control transformers, motors, and branch circuits in industrial control panels and electrical distribution systems.

Key Features & Specifications
  • Type: Current-limiting fuse, single barrel, Class CC
  • Voltage Rating: 600V AC
  • Current Rating: 1A
  • Dimensions: 1-1/2 inch length, 0.41 inch diameter
  • Standards: UL/CSA certified
  • Applications: Control transformers, motor circuits, branch circuit protection
  • AIC rating: 200kA@600V AC
  • Class Rating: CC
  • Barrels: 1
  • Weight: 0.02 lb
  • Family: Amp-Trap 2000
  • Country of Origin: Mexico


Product Identification
  • UPC: 782001908485
  • GTIN: 00782001908485
