Eaton Cutler Hammer 6232 - 100A 3-Pole Molded Case Circuit Breaker 600V
Eaton Cutler Hammer 6232 - 100A 3-Pole Molded Case Circuit Breaker 600V

Eaton Cutler Hammer 6232 - 100A 3-Pole Molded Case Circuit Breaker 600V

Cutler Hammer
Price
Save $-542.06
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton Cutler Hammer 6232 is a heavy-duty industrial circuit breaker designed for overcurrent protection in electrical distribution systems. It is rated for 600V AC and 100A continuous current, featuring a compact molded case construction with thermal-magnetic trip mechanism for precise fault interruption. The unit measures approximately 4.0 x 2.5 x 5.5 inches, weighs 5.19 lb, and is built with a rugged thermoplastic enclosure for durability in harsh environments. This breaker complies with UL 489 and CSA C22.2 standards, ensuring reliable performance in commercial and industrial applications such as motor control centers, panelboards, and switchgear. Typical uses include feeder protection, branch circuit isolation, and backup protection for transformers and machinery.

Key Features & Specifications
  • Type: Molded case circuit breaker, thermal-magnetic trip, thermoplastic enclosure
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 4.0 x 2.5 x 5.5 inches
  • Standards: UL 489, CSA C22.2
  • Applications: Feeder protection, branch circuit isolation, motor control centers, panelboards, switchgear
  • Breaker Type: Thermal-magnetic
  • Frame Size: 100A frame
  • Trip Type: Fixed thermal-magnetic
  • Poles: 3-pole
  • Voltage: 600V AC
  • Amperage: 100A
  • AIC rating: 10kA at 600V AC
  • Connection: Line and load lugs
  • Protection: Overcurrent and short-circuit
  • Functions: Overload and fault interruption
  • Panel Type: Suitable for panelboards and switchgear
  • Installation Type: Bolt-on or plug-in
  • Circuit Breaker Mounting Style: Bolt-on
  • Terminal Connection: Copper or aluminum lugs
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-phase
  • Compatible Frames: Eaton CH and BR series
  • Nema Rating: NEMA 1
  • Enclosure: Open type
  • Operating Temperature Maximum Celsius: 40°C
  • Weight: 5.19 lb


Product Identification
  • UPC: 0789593836172
  • GTIN: 00075352062327
