Eaton 5LCLS-9R - Medium Voltage Fuse 200A 5500V (50kA AIC)

Eaton
Price
Save $2,332.43
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5LCLS-9R is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It provides a 200A current rating and a 5500V voltage rating, engineered to interrupt high fault currents up to 50kA at 5.5kV. The fuse features a robust single-barrel construction with a 3-inch diameter and a 14-inch clip center spacing, contributing to its overall dimensions of 14 in x 3 in x 3 in and a weight of 10 lb. It complies with the IEEE Std. C37.41 standard and is typically applied in motor circuits, transformers, and capacitor banks where reliable Class R protection is required.

Key Features & Specifications
  • Type: Medium Voltage Current-Limiting (LCLS) Fuse, Single Barrel
  • Voltage Rating: 5500V
  • Current Rating: 200A
  • Dimensions: 14 in L x 3 in H x 3 in W (355.6 mm x 76.2 mm x 76.2 mm)
  • Standards: IEEE Std. C37.41
  • Applications: Protection for motors, transformers, and capacitor banks
  • AIC rating: 50kA @ 5.5kV
  • Class Rating: R
  • Clip Center: 14 in (355.6 mm)
  • Diameter: 3 in (76.2 mm)
  • Barrels: 1
  • Weight: 10 lb (4.54 kg)


Product Identification
  • UPC: 786670150787
  • GTIN: 00786670150787
