Eaton 5BCLS-44R - Class R Medium Voltage Fuse 800A 4800V
Eaton 5BCLS-44R - Class R Medium Voltage Fuse 800A 4800V
Eaton 5BCLS-44R - Class R Medium Voltage Fuse 800A 4800V
Eaton 5BCLS-44R - Class R Medium Voltage Fuse 800A 4800V

Eaton 5BCLS-44R - Class R Medium Voltage Fuse 800A 4800V

Eaton
Price
Save $3,585
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 5BCLS-44R is a medium-voltage current-limiting fuse designed for protecting electrical distribution equipment from short-circuit faults. It is rated for 4800V systems with a continuous current rating of 800A and an interrupting rating of 50kA at 5.5kV. The fuse features a robust two-barrel construction with a 3-inch diameter and bolt-in connection terminals spaced on 17.88-inch centers, housed within a compact assembly measuring 19.5 x 9 x 4.5 inches and weighing 30 lb. Manufactured to IEEE Std. C37.41, this Class R fuse is engineered for reliable performance in industrial power distribution and motor control applications.

Key Features & Specifications
  • Type: BCLS, Medium Voltage Current-Limiting Fuse, 2-Barrel Construction
  • Voltage Rating: 4800V
  • Current Rating: 800A
  • Dimensions: 19.5 in L x 9 in H x 4.5 in W
  • Standards: Certified to IEEE Std. C37.41
  • Applications: Industrial power distribution, motor circuit protection
  • Class Rating: R
  • AIC rating: 50kA @ 5.5kV
  • Connection: Bolt In
  • Clip Center: 17.88 in
  • Diameter: 3 in
  • Weight: 30 lb
  • Family: CLS Series
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782116317363
  • GTIN: 00782116317363
