Bussmann 5.5ABWNA0.5E - Medium Voltage Fuse 0.5A 5500V (Class E, 50kA AIC)

The Bussmann 5.5ABWNA0.5E is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power systems. It features a 5500V AC voltage rating with a 0.5A current rating and provides 50kA interrupting capacity at 5.5kV. Constructed as a single-barrel design with 1-inch diameter and 4.42-inch clip center spacing, this Class E fuse meets industry standards for medium voltage applications. Its current-limiting characteristics make it suitable for transformer protection, motor circuits, and feeder protection in industrial facilities and utility substations.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse, single barrel construction
• Voltage Rating: 5500V AC
• Current Rating: 0.5A
• Dimensions: 1" diameter, 4.42" clip center spacing
• Standards: Class E fuse rating
• Applications: Transformer protection, motor circuits, industrial power systems
• AIC rating: [email protected]
• Barrels: 1
• Class Rating: E
• Diameter: 1 inch
• Clip Center: 4.42 inches
• Weight: 1 lb
• Family: AB
• Country of Origin: India

Product Identification

• UPC: 051712835855
• GTIN: 00051712835855
