Siemens 3VA4150-6ED34-0AA0 - Molded Case 50A 600V AC
Siemens 3VA4150-6ED34-0AA0 - Molded Case 50A 600V AC

Siemens 3VA4150-6ED34-0AA0 - Molded Case 50A 600V AC

Siemens
Price
Save $-430.49
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
Siemens 3VA4150-6ED34-0AA0 is a 3VA4 molded case circuit breaker from the Sentron Series, designed for line protection with a thermal-magnetic trip unit. This 3-pole, 50A rated device operates at 600V AC and delivers a high interrupting capacity of 65kA at 480V AC, with a TM210 trip type providing fixed thermal overload protection at Ir=50A and short-circuit protection at Ii=10xIn. The unit measures 6.299 x 5.315 x 3.465 inches, weighs 1.638 lb, and features a bolt-on connection with load side lugs, housed in a UL frame size 125. It is UL Listed and certified, with an operating temperature range of -13°F to 158°F (-25°C to 70°C), and is manufactured in Mexico. This circuit breaker is suited for industrial applications requiring reliable overcurrent and short-circuit protection in three-phase systems.

Key Features & Specifications
  • Type: 3VA4 Molded Case Circuit Breaker
  • Manufacturer: Siemens
  • Family: Sentron Series
  • Item Subcategory: Molded Case
  • Country of Origin: Mexico
  • Dimensions: 6.299 x 5.315 x 3.465 inch
  • Weight: 1.638 lb
  • Terminal Connection: Load Side Lug
  • Functions: LI (Long-time/Instantaneous)
  • Frame Size: 125
  • Voltage Rating: 600V AC
  • Poles: 3
  • Connection: Bolt-On
  • Standards: UL Listed
  • Protection: Thermal Magnetic
  • Certification: UL Listed
  • AIC rating: 65kA@480V
  • Phase: 3
  • Trip Type: TM210
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Current Rating: 50A
  • Overload Protection: Ir=50A fixed
  • Short-Circuit Protection: Ii=10xIn
  • Interrupt Rating: 100kA@240V


Product Identification
  • UPC: 804766943966
  • GTIN: 804766943966
