Siemens 3VA4150-4ED34-0AA0 - Molded Case 50A 600V (3-Pole Thermal Magnetic)
Siemens 3VA4150-4ED34-0AA0 - Molded Case 50A 600V (3-Pole Thermal Magnetic)

Siemens 3VA4150-4ED34-0AA0 - Molded Case 50A 600V (3-Pole Thermal Magnetic)

Siemens
Price
Save $526.24
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens 3VA4150-4ED34-0AA0 Circuit Breaker - Molded Case 50A 600V (3-Pole Thermal Magnetic) The Siemens 3VA4150-4ED34-0AA0 is a 3-pole molded case circuit breaker from the Sentron Series, designed for thermal-magnetic protection (LI functions) in industrial power distribution systems. It is rated for 50A continuous current at 600V AC, with an interrupting capacity of 25kA at 480V, and operates on a 3-phase system. The unit features a 125A frame size, bolt-on connection, and load side lug terminals, measuring 6.299 x 5.315 x 3.465 inches and weighing 1.638 lb. It is UL Listed and certified, with a TM210 trip type and an operating temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suitable for branch circuit protection in switchboards, panelboards, and industrial control panels requiring reliable overcurrent and short-circuit interruption.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Sentron Series, 3VA, Thermal Magnetic
  • Voltage Rating: 600V AC
  • Current Rating: 50A
  • Dimensions: 6.299 x 5.315 x 3.465 inch
  • Standards: UL Listed
  • Applications: Industrial power distribution, branch circuit protection
  • Poles: 3
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI
  • Frame Size: 125
  • Trip Type: TM210
  • AIC rating: 25kA@480V
  • Phase: 3
  • Terminal Connection: Load Side Lug
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Weight: 1.638 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 804766943928
  • GTIN: 00804766943928
