Siemens 3VA4125-6ED34-0AA0 - Molded Case Breaker 25A 600V (3-Pole)
Siemens 3VA4125-6ED34-0AA0 - Molded Case Breaker 25A 600V (3-Pole)

Siemens 3VA4125-6ED34-0AA0 - Molded Case Breaker 25A 600V (3-Pole)

Siemens
Price
Save $-347.99
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens 3VA4125-6ED34-0AA0 is a 3-pole molded case circuit breaker from the Sentron Series, designed for thermal-magnetic protection (LI functions) in industrial power distribution systems. It is rated for 25A continuous current at 600V AC, with an interrupting capacity of 65kA at 480V, and features a TM210 trip type for precise overload and short-circuit protection. The unit measures 6.299 x 5.315 x 3.465 inches, weighs 1.638 lb, and utilizes a bolt-on connection with load side lugs, operating within a temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is UL Listed and certified for compliance with North American safety standards. Typical applications include branch circuit protection in industrial control panels, motor control centers, and commercial distribution boards requiring reliable overcurrent protection in 3-phase systems.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Sentron Series, 3VA
  • Voltage Rating: 600V AC
  • Current Rating: 25A
  • Dimensions: 6.299 x 5.315 x 3.465 inch
  • Standards: UL Listed
  • Applications: Industrial power distribution, branch circuit protection
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Coil Voltage Maximum: Not applicable (thermal-magnetic)
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: 6.299 x 5.315 x 3.465 inch
  • Phase: 3
  • Voltage: 600V AC
  • Amperage: 25A
  • AIC rating: 65kA@480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI
  • Frame Size: 125
  • Trip Type: TM210
  • Panel Type: Not specified
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Bolt-On
  • Hz: 50/60 Hz (assumed)
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not applicable
  • Full Load Amps: 25A
  • Dist Voltage: Not applicable
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 25A
  • Full Load Amp Minimum: 25A
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 25A
  • Amperage Minimum: 25A
  • Nema Rating: Not specified
  • Switch Style: Not applicable
  • Wire Size: Not specified
  • Certification: UL Listed
  • Circuit Breaker Mounting Style: Bolt-On
  • Terminal Connection: Load Side Lug
  • Frequency Rating: 50/60 Hz (assumed)
  • Phase Connection: 3-Phase
  • Standards: UL Listed
  • Compatible Frames: 125 Frame
  • Installation Type: Panelboard
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: 125
  • Current Rating: 25A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 804766943669
  • GTIN: 804766943669
