Eaton 2CLS-200 - Medium Voltage Fuse 2540V 9A (50kA AIC)

Eaton 2CLS-200 is a medium-voltage current-limiting fuse designed for high-interruption capacity protection in industrial power systems. Rated for 2540V AC with a 9A current rating, it features a robust single-barrel construction with 10.8" clip center spacing and complies with IEEE Std. C37.41 for medium-voltage applications. The fuse delivers 50kA interrupting capacity at 2.54kV in a compact 3" diameter package weighing 5.8 lb, making it suitable for transformer protection, motor circuits, and feeder protection in utility and industrial settings.

Key Features & Specifications

• Type: CLS series current-limiting fuse with standard connection
• Voltage Rating: 2540V AC
• Current Rating: 9A
• Dimensions: 3" diameter, 10.8" clip center
• Standards: IEEE Std. C37.41
• Applications: Transformer/motor protection, industrial feeders
• AIC rating: [email protected]
• Barrels: 1
• Weight: 5.8 lb
• Country of Origin: United States

Product Identification

• UPC: 786670500933
• GTIN: 00786670500933
