Eaton 2ACLS-6R - Medium Voltage Fuse 170A (2540V, 50kA AIC)

Eaton
Price
Save $-1,796.93
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 2ACLS-6R is a medium voltage current-limiting fuse designed for protecting electrical equipment in industrial power distribution systems. It provides a 170A current rating and a 2540V voltage rating for reliable circuit interruption. The fuse features a single-barrel construction with a 3-inch diameter and overall dimensions of 10.8 in x 4.2 in x 3 in, weighing 5.9 lb for robust mechanical integration. It is engineered to meet IEEE Std. C37.41 and offers a high interrupting capacity of 50kA at 2.54kV. Typical applications include safeguarding transformers, motors, and capacitor banks in utility and industrial medium-voltage networks.

Key Features & Specifications
  • Type: ACLS medium voltage, current-limiting fuse, single-barrel construction
  • Voltage Rating: 2540V
  • Current Rating: 170A
  • Dimensions: 10.8 in (Length/Depth) x 4.2 in (Height) x 3 in (Width)
  • Standards: IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and capacitor banks in industrial power distribution
  • Class Rating: R
  • AIC rating: 50kA @ 2.54kV
  • Diameter: 3 in
  • Barrels: 1
  • Weight: 5.9 lb
  • Country of Origin: Canada
  • Family: CLS


Product Identification
  • UPC: 786670220916
  • GTIN: 00786670220916
