Bussmann 170M6251 - KN110 Fuse 1400A (100kA@1100V)

Bussmann
Price
Save $2,551.84
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 170M6251 is a low-voltage current-limiting fuse designed for high-capacity circuit protection in industrial power distribution systems. It provides a 1400A current rating and a 1100V voltage rating, capable of interrupting faults up to 100kA at its rated voltage. The fuse features a robust stud connection type and compact dimensions of 168 mm x 76 mm x 95 mm, with a Class aR rating indicating its partial-range backup protection for semiconductor devices. It is engineered for demanding applications such as protecting bus bars, service entrances, and industrial machinery where high interrupting capacity and reliable performance are critical.

Key Features & Specifications
  • Type: KN110, Low Voltage Current-Limiting Fuse, Stud Connection
  • Voltage Rating: 1100V
  • Current Rating: 1400A
  • Dimensions: 168 mm x 76 mm x 95 mm (Length/Depth x Height x Width)
  • Weight: 2.0217 lb
  • Class Rating: aR (Partial Range)
  • AIC Rating: 100kA @ 1100V
  • Connection: Stud
  • Item Subcategory: Low Voltage Fuse


Product Identification
  • UPC: 051712793520
  • GTIN: 00051712793520
