Eaton 15BHLE-175E - Medium Voltage Fuse 15.5kV/175A (63kA AIC, IEEE C37.41)
Regular price
$3,172.46
$3,172.46
Regular price
$3,450.86
$3,450.86
Sale price
$3,172.46
$3,172.46
Save $278.40
/
- In stock, ready to ship
- Backordered, shipping soon
Eaton 15BHLE-175E is a medium voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 15.5kV systems with a 175A continuous current rating, it features a bolt-on connection and dual-barrel construction with a 3-inch diameter for robust performance. The fuse meets IEEE Std. C37.41 standards and delivers 63kA interrupting capacity at rated voltage for reliable fault protection. Its Class E rating and 21-inch clip center spacing make it suitable for switchgear, transformers, and motor circuits in utility and heavy industrial applications.
Key Features & Specifications
Key Features & Specifications
- Type: BHLE dual-barrel current-limiting fuse with silver-sand elements
- Voltage Rating: 15,500V AC
- Current Rating: 175A continuous
- Dimensions: 3" diameter, 21" clip center spacing
- Standards: IEEE Std. C37.41 compliant
- Applications: Switchgear, transformers, motor circuits
- Class Rating: E
- Connection: Bolt-On
- Barrels: 2
- AIC rating: [email protected]
- Weight: 11.5 lb
- Country of Origin: Dominican Republic
- UPC: 782116108213
- GTIN: 00782116108213
Quote Request
