Eaton 15LHLE-150E - Medium Voltage Fuse 15.5kV/150A (63kA AIC)

Eaton 15LHLE-150E is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 15,500V AC with a 150A current capacity, it features a single-barrel Class E construction with a 63kA interrupting capacity at 15.5kV. The fuse measures 10.76" x 7.15" x 6.06" (LxHxW) with 8" clip centers and weighs 5.9 lb, built to withstand demanding electrical environments. It meets industry standards for medium-voltage protection applications, including transformer and feeder circuit protection in utility and industrial power distribution systems.

Key Features & Specifications

• Type: Current-limiting medium-voltage fuse (Class E)
• Voltage Rating: 15,500V AC
• Current Rating: 150A
• Dimensions: 10.76" L x 7.15" H x 6.06" W
• Weight: 5.9 lb
• Diameter: 3"
• Barrels: 1
• AIC Rating: 63kA @ 15.5kV
• Clip Center: 8"
• Standards: Meets industry requirements for medium-voltage protection
• Applications: Transformer protection, feeder circuits, industrial power distribution

Product Identification

• UPC: 786685494999
• GTIN: 00786685494999
