Eaton 15BHLE-150E - Medium Voltage Fuse 15.5kV/150A (63kA AIC @ 15.5kV)
Regular price
$2,743.85
$2,743.85
Regular price
$3,450.86
$3,450.86
Sale price
$2,743.85
$2,743.85
Save $707.01
/
- In stock, ready to ship
- Backordered, shipping soon
Eaton 15BHLE-150E is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 15,500V AC operation with a 150A current rating, this bolt-on fuse features a two-barrel construction with a 3-inch diameter and 15-inch clip center spacing for secure mounting. Compliant with IEEE Std. C37.41 standards, it delivers 63kA interrupting capacity at 15.5kV for reliable fault protection in utility substations, industrial plants, and large commercial power distribution systems.
Key Features & Specifications
Key Features & Specifications
- Type: BHLE class E current-limiting fuse with bolt-on connection
- Voltage Rating: 15,500V AC
- Current Rating: 150A
- Dimensions: 3" diameter, 15" clip center spacing
- Standards: IEEE Std. C37.41 compliant
- Applications: Utility substations, industrial power distribution
- Class Rating: E
- Connection: Bolt-On
- Barrels: 2
- AIC rating: [email protected]
- Weight: 21 lb
- Country of Origin: Dominican Republic
- UPC: 782116108206
- GTIN: 00782116108206
Quote Request
