Littelfuse JTD080 - Class J Time-Delay Fuse 600V/200kA (Bolt-In Connection)

Littelfuse JTD080 is a Class J time-delay fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 200kA interrupting capacity, providing reliable overcurrent protection for high-energy circuits. The fuse measures 4-5/8" in length with a 1.13" diameter bolt-in construction, manufactured with durable materials for robust performance. Certified to UL 248-8 Class J, CE, and CSA standards, it meets stringent safety requirements for industrial applications including motor protection, transformers, and power distribution equipment.

Key Features & Specifications

• Type: Class J time-delay low-voltage fuse with bolt-in connection
• Voltage Rating: 600V AC/DC
• AIC Rating: 200kA
• Dimensions: 4-5/8" length x 1.13" diameter
• Standards: UL 248-8 Class J, CE, UL Listed, CSA Certified
• Applications: Motor circuits, transformers, industrial power distribution
• Class Rating: J
• Connection: Bolt-In
• Velocity: Time Delay (TD)
• Country of Origin: Mexico

Product Identification

• UPC: 079458202229
