Bussmann 15NCLPT-1E-A - Medium Voltage Fuse 1A 15.5kV (Class E, 50kA AIC)

Bussmann 15NCLPT-1E-A is a medium voltage fuse designed for overcurrent protection in high-voltage electrical systems. This Class E rated fuse operates at 15.5kV with a 1A current rating and provides 50kA interrupting capacity at rated voltage. The fuse features a single-barrel ferrule connection design with compact dimensions of 12.9 inches in length and 1.6-inch diameter, weighing 2 pounds for robust construction. Certified to IEEE Std. C37.41 standards, this fuse ensures reliable performance in industrial power distribution applications including transformer protection and motor circuit protection where medium voltage coordination is required.

Key Features & Specifications

• Type: Medium Voltage Current Limiting Power Fuse, NCLPT type, single barrel ferrule connection
• Voltage Rating: 15,500V AC
• Current Rating: 1A
• Dimensions: 12.9" length × 1.6" width × 1.6" height
• Standards: IEEE Std. C37.41
• Applications: Industrial power distribution, transformer protection, motor circuit protection
• Class Rating: E
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Diameter: 1.62 inches
• Clip Center: 11.5 inches
• Weight: 2 lb
• Certification: IEEE Std. C37.41

Product Identification

• UPC: 051712526999
• GTIN: 00786679109458
