Bussmann 155GXQSJ175E - Class E Medium Voltage Fuse 175A (65kA AIC @ 15.5kV)

The Bussmann 155GXQSJ175E is a Class E medium voltage fuse designed for overcurrent protection in industrial power distribution systems. It features a 175A current rating and 15.5 kV voltage rating with a 65kA interrupting capacity at rated voltage. The fuse construction utilizes a single-barrel design with DIN connection interface, measuring 3.464 inches in diameter and 20.078 inches in length with a weight of 11.5 lb. This fuse meets industry standards for medium voltage applications and is typically deployed in motor protection circuits, transformer protection, and feeder circuit applications requiring high interrupting capacity.

Key Features & Specifications

• Type: Medium Voltage Fuse, Class E, single-barrel construction
• Voltage Rating: 15.5 kV
• Current Rating: 175A
• Dimensions: 3.464 in x 20.078 in x 3.464 in (Height x Length x Width)
• Standards: Industry standards for medium voltage protection
• Applications: Industrial power distribution, motor protection, transformer circuits
• AIC rating: [email protected]
• Connection: DIN
• Barrels: 1
• Class Rating: E
• Diameter: 89 mm
• Clip Center: 537 mm
• Weight: 11.5 lb

Product Identification

• UPC: 051712691918
• GTIN: 00051712691918
