Square D VH364N - Fusible Disconnect Switch 600V AC/DC 200A (3-Pole NEMA 1)

Square D VH364N is a fusible safety disconnect switch designed for industrial power distribution systems requiring reliable circuit isolation. This UL-listed and RoHS-compliant unit features a 600V AC/DC voltage rating with 200A current capacity across three poles, housed in a NEMA 1-rated enclosure measuring 16.5" x 29" and weighing 24.7 lb. Its single-configuration fusible switch design provides robust protection for three-phase applications, meeting stringent safety standards including UL file E2875. The switch is engineered for heavy-duty electrical systems requiring manual disconnection capabilities in manufacturing plants and commercial facilities.

Key Features & Specifications

• Type: Fusible safety disconnect switch with manual operation
• Voltage Rating: 600V AC/DC
• Current Rating: 200A
• Dimensions: 16.5" x 29" (419mm x 737mm)
• Standards: UL listed (file E2875), EU RoHS compliant
• Applications: Industrial power distribution, motor control centers
• Configuration: Single
• Poles: 3
• Phase: 3-phase
• NEMA Rating: NEMA 1
• Switch Style: Fusible
• Wire: 3-wire
• Weight: 24.7 lb (11.2 kg)
• Country of Origin: United States

Product Identification

• UPC: 060648589425
• GTIN: 03606485894256
