Cutler Hammer FDPWT3623 - Fusible Safety Switch 600V/100A (3-Pole, 200kA AIC)

Cutler Hammer FDPWT3623 is a panel-mounted fusible safety switch designed for industrial power distribution systems requiring high fault current protection. The unit features a 600V AC voltage rating and 100A current capacity in a compact 3-phase configuration with dual/twin pole operation. Its rugged NEMA 1 enclosure houses R/H/K class fuses and provides 200kA interrupting capacity at 480V, meeting critical safety standards for heavy-duty applications. The switch is engineered for compatibility with SFPA frames and weighs 35 lb for secure panel mounting. Typical applications include motor control centers, machinery power disconnects, and industrial facility main distribution panels.

Key Features & Specifications

• Type: Fusible safety switch, panel mount, Type FDP family
• Voltage Rating: 600V AC
• Current Rating: 100A
• Configuration: Dual/Twin
• Poles: 3
• Phase: 3
• AIC Rating: 200kA@480V
• Fuse Class: R, H, K
• NEMA Rating: 1
• Compatible Frames: SFPA
• Weight: 35 lb
• Switch Style: Fusible
• Standards: Industrial safety compliance
• Applications: Motor control centers, industrial power distribution
