Cutler Hammer FDPWT3611R - Fusible Safety Switch 600V 30A (200kA AIC 3-Pole)

The Cutler Hammer FDPWT3611R is a Type FDP panel-mounted fusible safety switch designed for industrial circuit protection and isolation. This 600V AC rated switch handles 30A current with a 200kA interrupting capacity at 480V, featuring a robust three-pole dual/twin configuration for comprehensive phase protection. Constructed with a NEMA 1 enclosure measuring 22.5" x 10.3" x 8" and weighing 25 lb, the unit accommodates R, H, and K class fuses with wire compatibility from 14 to 1/0 AWG for both copper and aluminum conductors. UL certified and compatible with SEHA frames, this switch meets industrial safety standards for reliable operation in demanding three-phase electrical distribution systems, manufacturing facilities, and industrial control applications where secure circuit isolation and overload protection are critical.

Key Features & Specifications

• Type: Panel-mounted fusible safety switch, dual/twin configuration
• Voltage Rating: 600V AC
• Current Rating: 30A
• Dimensions: 22.5" L x 10.3" H x 8" W
• Standards: UL certified, NEMA 1 rated
• Applications: Industrial electrical distribution, manufacturing facilities, three-phase power systems
• Switch Type: Fusible safety switch
• Configuration: Dual/Twin
• Poles: 3
• AIC rating: 200kA@480V
• Phase: 3-phase
• Fuse Class: R, H, K
• Wire Size: 14 to 1/0 AWG (Copper/Aluminum)
• Compatible Frames: SEHA
• Weight: 25 lb
• Enclosure: NEMA 1
• Family: Type FDP
• Country of Origin: Mexico

Product Identification

• UPC: 786679651520
• GTIN: 00786679047668
