Cutler Hammer FDPWS322R - Fusible Disconnect Switch 60A @ 240V (200kA AIC, 3-Pole)

Cutler Hammer FDPWS322R is a fusible disconnect switch designed for industrial power distribution systems, providing reliable circuit protection with a 200kA interrupting capacity at 240V. This UL-listed panel-mount switch features a 60A current rating and 3-pole configuration, housed in a NEMA 1-rated enclosure measuring 22.4"L x 10.2"H x 7.8"W with a 25 lb rugged construction. Compliant with industrial safety standards, it accepts R, H, and K-class fuses and is compatible with SGHA frames for three-phase applications requiring robust circuit isolation.

Key Features & Specifications

• Type: Fusible disconnect switch (Type FDPWS), panel-mount
• Voltage Rating: 240V AC
• Current Rating: 60A
• Dimensions: 22.4" x 10.2" x 7.8" (LxHxW)
• Standards: UL Listed, NEMA 1 enclosure
• Applications: Industrial power distribution, motor control
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• AIC Rating: 200kA @ 240V
• Phase: 3
• Fuse Class: R, H, K
• Weight: 25 lb
• Compatible Frames: SGHA
• Country of Origin: Mexico

Product Identification

• UPC: 782114289112
• GTIN: 00782114289112
