Cutler Hammer FDPW366MJ - Fusible Safety Switch 600A (200kA AIC @480V)

Cutler Hammer FDPW366MJ is a fusible safety switch designed for industrial power distribution systems requiring high fault current protection. This UL-listed panel-mount switch features a 600V/600A rating with a 200kA interrupting capacity at 480V, housed in a NEMA 1 enclosure measuring 24.5"L x 16.3"W x 10"H and weighing 75 lb. The three-pole single-configuration switch utilizes Class J fuses and is compatible with TFJ frames, meeting rigorous industrial safety standards for three-phase applications where reliable circuit isolation is critical.

Key Features & Specifications

• Type: Fusible safety switch, panel mount
• Voltage Rating: 600V AC
• Current Rating: 600A
• Dimensions: 24.5" x 16.3" x 10" (LxWxH)
• Weight: 75 lb
• Standards: UL Listed
• Applications: Industrial power distribution, motor control centers
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• AIC rating: 200kA@480V
• Nema Rating: 1
• Phase: 3
• Fuse Class: J
• Compatible Frames: TFJ
• Country of Origin: Mexico

Product Identification

• UPC: 786679783962
• GTIN: 00786679783962
