Cutler Hammer FDPW366J - Class J Fusible Disconnect Switch (600A, 600V, 200kA AIC)
Regular price
$5,891.49
$5,891.49
Regular price
$2,879.00
$2,879.00
Sale price
$5,891.49
$5,891.49
Save $-3,012.49
/
- Low stock - 2 items left
- Backordered, shipping soon
Cutler Hammer FDPW366J is a fusible panel-mounted disconnect switch designed for high-current industrial power distribution systems. This UL-listed switch features a 600V voltage rating and 600A current capacity with a 200kA interrupting rating at 480V for robust circuit protection. The NEMA 1-rated enclosure measures 25"L x 16"W x 10.5"H and weighs 75 lb, constructed with Class J fuse compatibility for three-phase applications. Compliant with UL standards, it integrates with TFJ frames for industrial panel installations requiring reliable power isolation in manufacturing plants and heavy machinery applications.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Fusible disconnect switch, panel-mounted
- Voltage Rating: 600V AC
- Current Rating: 600A
- Dimensions: 25"L x 16"W x 10.5"H (635mm x 406mm x 267mm)
- Standards: UL Listed
- Applications: Industrial power distribution, heavy machinery
- Switch Style: Fusible
- Configuration: Single
- Poles: 3
- Phase: 3
- AIC Rating: 200kA@480V
- Fuse Class: J
- NEMA Rating: 1
- Compatible Frames: TFJ
- Weight: 75 lb (34 kg)
- Country of Origin: Mexico
Product Identification
- UPC: 786679783931
- GTIN: 00786679783931
Quote Request
