Square D DTU224NRB - Non-Fusible Disconnect Switch 200A 240V AC/DC (NEMA 3R)
Regular price
$2,058.77
$2,058.77
Regular price
$2,177.00
$2,177.00
Sale price
$2,058.77
$2,058.77
Save $118.23
/
- In stock, ready to ship
- Backordered, shipping soon
Square D DTU224NRB is a non-fusible safety disconnect switch designed for reliable circuit isolation and load breaking in industrial applications. It features a 240V AC/DC voltage rating with 200A current capacity and 200kA interrupting rating at 240V for robust electrical protection. The unit measures 24" x 10.63" x 32.5" (WxDxH) and weighs 31.69 lb, constructed with NEMA 3R rated enclosure for outdoor durability. UL listed certification ensures compliance with industry safety standards, making it suitable for industrial power distribution systems, motor control centers, and main service disconnects where reliable circuit isolation is critical.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Non-fusible safety disconnect switch, Series E family, DTU type
- Voltage Rating: 240V AC/DC
- Current Rating: 200A
- Dimensions: 24" x 10.63" x 32.5" (WxDxH)
- Standards: UL listed, NEMA 3R rated
- Applications: Industrial power distribution, motor control centers, main service disconnects
- Switch Type: Non-Fusible
- Configuration: Single
- Phase: 1
- Poles: 2
- AIC rating: 200kA@240V
- Wire Size: AWG 6 to 300KCmil Copper/Aluminum
- Compatible Frames: RLF
- Weight: 31.69 lb
- Country of Origin: United States
Product Identification
- UPC: 785901174523
- GTIN: 00785901174523
