Cutler Hammer DT364UGK - Non-Fusible Disconnect Switch 200A@600V (100kA AIC)

Cutler Hammer DT364UGK is a heavy-duty industrial disconnect switch designed for safe power isolation in high-capacity electrical systems. This UL-listed, 3-phase non-fusible switch features a 600V voltage rating and 200A current capacity with a robust 100kA@600V AIC rating for fault protection. The NEMA 1-rated enclosure measures 19.15" x 11.26" x 37.69" (WxDxH) and weighs 134 lb, constructed with double-break contacts for reliable operation. Compliant with UL standards, it's engineered for compatibility with SEDA frames in industrial power distribution, motor control centers, and main service disconnects.

Key Features & Specifications

• Type: DT Series non-fusible safety disconnect switch
• Voltage Rating: 600V AC
• Current Rating: 200A
• Dimensions: 19.15 x 11.26 x 37.69 inches (WxDxH)
• Standards: UL Listed
• Applications: Industrial power distribution, MCCs, service entrances
• Configuration: Double-break
• Poles: 3
• AIC rating: 100kA@600V
• NEMA Rating: NEMA 1
• Phase: 3-phase
• Compatible Frames: SEDA
• Weight: 134 lb
• Country of Origin: United States

Product Identification

• UPC: 782113613970
• GTIN: 00782114000000
