Cutler Hammer DH366FDK - Fusible Disconnect Switch 600A 600V (100kA AIC @600V)

Cutler Hammer DH366FDK is a fusible safety disconnect switch designed for industrial power distribution systems requiring high-interrupting capacity protection. This UL-listed, NEMA 12-rated switch features a 600V/600A rating with a 100kA AIC at 600V for robust circuit protection in demanding environments. The unit's rugged construction measures 23" W x 12.75" D x 63" H and weighs 240 lb, featuring a 3-pole single configuration with Class R fuse compatibility. Compliant with NEC 230.62(C) barrier requirements, it's engineered for use with TEB frames in three-phase applications requiring reliable isolation and overcurrent protection.

Key Features & Specifications

• Type: Fusible safety disconnect switch, DH Series
• Voltage Rating: 600V AC
• Current Rating: 600A
• Dimensions: 23" x 12.75" x 63" (WxDxH)
• Standards: UL Listed, NEC 230.62(C) compliant
• Applications: Industrial power distribution, motor control centers
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• Phase: 3
• AIC Rating: 100kA@600V
• Fuse Class: R
• NEMA Rating: NEMA 12
• Compatible Frames: TEB
• Weight: 240 lb

Product Identification

• UPC: 782113207636
• GTIN: 00782113000000
