Cutler Hammer DH325FRK - Fusible Disconnect Switch 400A@240V (100kA AIC)

Cutler Hammer DH325FRK is a fusible safety disconnect switch designed for industrial power distribution protection. This UL-listed 3-pole switch handles 400A at 240V AC with a 100kA interrupting capacity, featuring rugged NEMA 3R-rated construction for outdoor durability. The unit measures 24.38" W x 45.5" D x 10.25" H with a 150 lb steel enclosure, compatible with THLC frames and Class R fuses. Compliant with UL safety standards, it's engineered for three-phase systems in manufacturing plants, data centers, and heavy machinery applications requiring reliable circuit isolation.

Key Features & Specifications

• Type: Fusible safety disconnect switch (Class R fuse compatible)
• Voltage Rating: 240V AC
• Current Rating: 400A
• Dimensions: 24.38" x 45.5" x 10.25" (WxDxH)
• Weight: 150 lb
• Standards: UL Listed, NEMA 3R
• Applications: Industrial power distribution, machinery control
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• AIC rating: 100kA@240V
• Phase: 3
• Fuse Class: R
• Compatible Frames: THLC
• Country of Origin: United States

Product Identification

• UPC: 782113207056
• GTIN: 00782113000000
