Schneider Electric 2601AF2 - Class J Fuse 200A 600V (200kA Interrupting Rating)
Regular price
$155.17
$155.17
Regular price
$172.45
$172.45
Sale price
$155.17
$155.17
Save $17.28
/
- Low stock - 4 items left
- Backordered, shipping soon
Schneider Electric 2601AF2 is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and 200A current capacity, housed in a durable ceramic body with silver-plated copper end caps for reliable conductivity. The fuse meets UL 248-12 standards and is CSA certified for safety compliance. Typical applications include motor control centers, switchgear, and transformer protection where high interrupting capacity is required.
Key Features & Specifications
Key Features & Specifications
- Type: Current-limiting Class J fuse with ceramic body and silver-plated copper terminals
- Voltage Rating: 600V AC
- Current Rating: 200A
- Dimensions: 3.5" x 1.5" (88.9mm x 38.1mm)
- Standards: UL 248-12, CSA certified
- Applications: Motor control centers, switchgear, transformer protection
- Interrupting Rating: 200kA
- Mounting: Bolt-on terminal connection
- Temperature Rating: -40°C to 100°C
- Material: Ceramic body with copper alloy elements
