Cutler Hammer TRS250RID - Class RK5 Fuse 250A 600V (200kA AIC)
Regular price
$273.63
$273.63
Regular price
$445.41
$445.41
Sale price
$273.63
$273.63
Save $171.78
/
- Low stock - 6 items left
- Backordered, shipping soon
The Cutler Hammer TRS250RID is a Class RK5 low-voltage current-limiting fuse designed to provide reliable overcurrent protection in industrial electrical systems. It features a 250A current rating and 600V voltage rating with an impressive 200kA interrupting capacity at 600VAC for robust short-circuit protection. The fuse employs a single-barrel construction with a 2.06-inch diameter and weighs 3 lb, utilizing time-delay characteristics to prevent nuisance tripping from motor starting currents. This Tri-Onic series fuse meets industry standards for current-limiting performance and is UL listed for safety compliance. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where high-interrupting capacity and selective coordination are required.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Class RK5 current-limiting time-delay fuse, single barrel construction
- Voltage Rating: 600V AC
- Current Rating: 250A
- Dimensions: 2.06" diameter
- Standards: UL listed, current-limiting classification
- Applications: Motor branch circuits, feeder circuits, industrial control panels
- AIC rating: 200,000A at 600V
- Class Rating: RK5
- Barrels: 1
- Weight: 3 lb
- Family: Tri-Onic
- Item Subcategory: Low Voltage Fuse
Product Identification
- UPC: 78200141524
- GTIN: 00782001415242
