Cutler Hammer TRS25 - Class RK5 Fuse 25A 600V (100kA AIC)

The Cutler Hammer TRS25 is a Class RK5 low-voltage current-limiting fuse designed to provide reliable circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and 25A current rating with an interrupting capacity of 100,000 amperes at 600V AC. The single-barrel construction utilizes time-delay characteristics to prevent nuisance tripping from motor starting currents and other temporary overloads. This fuse complies with industry standards for RK5 classification and is UL recognized for safety and performance. Typical applications include protection of motor circuits, transformers, and feeder circuits in industrial control panels and power distribution equipment.

Key Features & Specifications

• Type: TRS Class RK5 current-limiting time-delay fuse
• Voltage Rating: 600V AC
• Current Rating: 25A
• Dimensions: Standard RK5 dimensions
• Standards: UL recognized, Class RK5
• Applications: Motor circuit protection, transformer protection, feeder circuit protection
• AIC rating: 100kA@600V AC
• Class Rating: RK5
• Barrels: 1
• Weight: 5.19 lb
• Family: Tri-Onic

Product Identification

• UPC: 782001748852
