Cutler Hammer TRS225RID - Class RK5 Fuse 225A (200kA AIC @600V)

The Cutler Hammer TRS225RID is a Class RK5 low-voltage current-limiting fuse designed to provide reliable overcurrent protection for industrial electrical systems. It features a 225A current rating and 600V voltage rating with a high 200kA interrupting capacity at 600V AC for effective short-circuit protection. The fuse construction utilizes a single-barrel design with a 2.06-inch diameter and weighs 3 lb, engineered for durable performance in demanding environments. This fuse meets industry standards for current-limiting protection and is UL listed for safety compliance. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where high-interrupting capacity protection is required.

Key Features & Specifications

• Type: Class RK5 current-limiting fuse, single barrel design
• Voltage Rating: 600V AC
• Current Rating: 225A
• Dimensions: 2.06-inch diameter
• Standards: UL listed, current-limiting protection
• Applications: Motor branch circuits, feeder circuits, industrial control panels
• AIC rating: 200kA@600V AC
• Class Rating: RK5
• Barrels: 1
• Weight: 3 lb

Product Identification

• UPC: 782001415235
