Cutler Hammer TRS17-1/2RID - Class RK5 Fuse 17A 600V (200kA AIC)

The Cutler Hammer TRS17-1/2RID is a Class RK5 time-delay fuse designed to provide reliable circuit protection against overloads and short circuits in industrial electrical systems. It features a 600V AC voltage rating and a 17A current rating, ensuring compatibility with a wide range of industrial control circuits. The fuse is constructed as a single-barrel unit with a diameter of 0.56 inches and a weight of 5.19 lb, built to the Tri-Onic family specifications for robust performance. It complies with industry standards for current-limiting fuses, offering a high 200,000A interrupting rating at 600V AC for enhanced safety. This fuse is typically applied in motor branch circuits, transformers, and other equipment requiring dual-element, time-delay protection.

Key Features & Specifications

• Type: Class RK5, Tri-Onic dual-element time-delay fuse, current-limiting
• Voltage Rating: 600V AC
• Current Rating: 17A
• Dimensions: 0.56" diameter
• Standards: UL/CSA Listed, Class RK5
• Applications: Motor branch circuits, transformers, industrial controls
• AIC rating: 200kA @ 600V AC
• Barrels: 1
• Weight: 5.19 lb
• Family: Tri-Onic
• Item Subcategory: Low Voltage
