Cutler Hammer TRS12RID - RK5 Class Fuse 12A 600V (200kA AIC Rating)

Cutler Hammer TRS12RID is a low voltage current-limiting fuse designed for overcurrent protection in industrial electrical systems. It features a 12A current rating and 600V AC voltage rating with a high 200kA interrupting capacity at 600V for reliable circuit protection. The fuse construction includes a single-barrel design with a 0.56-inch diameter and RK5 class rating, providing time-delay characteristics and excellent short-circuit protection. It meets industry standards for industrial fuse applications and is commonly used in motor branch circuits, transformers, and power distribution equipment where coordinated protection is required.

Key Features & Specifications

• Type: Low voltage current-limiting fuse, single barrel, RK5 class with time-delay characteristics
• Voltage Rating: 600V AC
• Current Rating: 12A
• Dimensions: 0.56-inch diameter
• Standards: Industrial fuse standards for coordinated protection
• Applications: Motor branch circuits, transformers, power distribution systems
• AIC rating: 200kA@600V
• Class Rating: RK5
• Barrels: 1
• Weight: 0.2 lb

Product Identification

• UPC: 782001415037
• GTIN: 00782001000000
