Mersen TR1-6/10 - Low Voltage Fuse 600V AC (6-10A Time-Delay Protection)

Mersen TR1-6/10 is a low-voltage current-limiting fuse designed for overcurrent protection in industrial electrical systems. It features a 600V AC voltage rating and 6-10A current range, housed in a compact, durable ceramic body with silver-plated end caps for reliable conductivity. The fuse meets UL 248-10 and IEC 60269 standards, ensuring compliance with international safety requirements. Typical applications include motor protection, transformer circuits, and power distribution panels in manufacturing and utility environments.

Key Features & Specifications

• Type: Current-limiting fuse with ceramic body and silver-plated terminals
• Voltage Rating: 600V AC
• Current Rating: 6-10A
• Dimensions: 10.3mm diameter x 38.1mm length
• Standards: UL 248-10, IEC 60269
• Applications: Motor circuits, transformers, industrial power distribution
• Fuse Class: TR (Time-Delay)
• Interrupting Rating: 200kA
• Mounting: Clip-mounted
• Operating Temperature: -40°C to +100°C
