Bussmann TPL-BD - Low Voltage Power Fuse 100A 170VDC (100kA AIC Rating)

Bussmann TPL-BD is a low voltage power fuse designed for high-interrupting capacity protection in DC power systems. This 100A rated fuse operates at 170VDC with a 100kA interrupting rating, providing reliable circuit protection in demanding applications. The single-barrel construction features a 1.5-inch diameter body with bolt-type connections for secure installation in industrial settings. Manufactured to meet industry standards for DC power protection, this Telpower family fuse is commonly used in telecommunications, renewable energy, and industrial control systems where high DC fault currents are present.

Key Features & Specifications

• Type: TPL series low voltage power fuse, single barrel construction with bolt connection
• Voltage Rating: 170VDC
• Current Rating: 100A
• Dimensions: 1.5-inch diameter
• Standards: Industry standard DC power fuse compliance
• Applications: Telecommunications, renewable energy systems, industrial DC power distribution
• AIC rating: 100kA@170VDC
• Connection: Bolt
• Barrels: 1
• Family: Telpower

Product Identification

• UPC: 051712813822
