Eaton SEC60 - Class J Fuse 600V/60A (200kA Interrupt Rating)

Eaton SEC60 is a low-voltage current-limiting fuse designed for short-circuit protection in industrial electrical systems. Rated for 600V AC/DC applications with current ratings up to 60A, it features a compact ceramic body construction with silver-element design for reliable operation. The fuse meets UL 248-10 and IEC 60269 standards for branch circuit protection. Typical applications include motor control centers, panelboards, and industrial machinery requiring high interrupting capacity.

Key Features & Specifications

• Type: Current-limiting fuse with ceramic body and silver-element construction
• Voltage Rating: 600V AC/DC
• Current Rating: 60A maximum
• Dimensions: 60mm length x 22mm diameter
• Standards: UL 248-10, IEC 60269 compliant
• Applications: Motor protection, transformer circuits, industrial control panels
• Interrupting Rating: 200kA at 600V AC
• Fuse Class: Class J
• Operating Temperature: -40°C to +100°C
• Mounting: Bolt-on terminal connection
