Bussmannn RES-40 - Class H Renewable Fuse 40A@600V (10kA AIC Rating)

Bussmannn RES-40 is a Class H low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC/DC voltage rating and 40A current rating, with a compact cylindrical design measuring 5.5" (139.7mm) in length and 1.06" (26.9mm) in diameter. The RoHS-compliant fuse offers 10kA interrupting capacity at 600V, constructed with durable materials for reliable performance in demanding environments. Typical applications include motor control centers, industrial machinery, and power distribution panels requiring robust overcurrent protection.

Key Features & Specifications

• Type: Class H renewable fuse with single barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 40A
• Dimensions: 5.5" x 1.06" (139.7mm x 26.9mm)
• Weight: 1 lb
• Standards: RoHS Compliant
• Applications: Industrial power distribution, motor protection
• AIC rating: 10kA@600V
• Class Rating: H
• Barrels: 1

Product Identification

• UPC: 051712110402
