Cutler Hammer OTS40 - K-5 Class Fuse 40A 600V (50kA AIC Rating)

Cutler Hammer OTS40 is a low-voltage current-limiting fuse designed for industrial circuit protection applications. It features a 40A current rating and 600V voltage rating with a 50kA interrupting capacity at 600V for reliable fault protection. The fuse has a compact single-barrel construction measuring 5-1/2 inches in length with a 1.06-inch diameter and weighs 0.23 lb, built to K-5 class specifications. It complies with industry standards for current-limiting protection in industrial environments. Typical applications include motor circuit protection, transformer protection, and industrial control panel applications where reliable current limitation is required.

Key Features & Specifications

• Type: Low-voltage current-limiting fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 40A
• Dimensions: 5-1/2 inches length, 1.06-inch diameter
• Weight: 0.23 lb
• Standards: K-5 class rating
• Applications: Motor circuit protection, transformer protection, industrial control panels
• AIC rating: 50kA@600V
• Barrels: 1
• Class Rating: K-5
• Diameter: 1.06 inches
• Mounting: Standard fuse clip

Product Identification

• UPC: 78200170076
• GTIN: 00782001700768
