Cooper Bussmann NON-65 - Class H Fuse 65A (10kA@250V Interrupt Rating)

Cooper Bussmann NON-65 is a Class H low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 250V AC/DC operation with a 65A current capacity, it provides 10kA interrupting capacity at rated voltage in a compact cylindrical form factor measuring 5.88" in length and 1.06" in diameter. The single-barrel construction meets UL/CSA standards for Class H fuses, featuring durable materials suitable for motor control centers, switchgear, and power distribution panels where reliable overcurrent protection is required.

Key Features & Specifications

• Type: Class H non-renewable fuse with single-element construction
• Voltage Rating: 250V AC/DC
• Current Rating: 65A
• Dimensions: 5.88" L × 1.06" W × 1.06" H (149.4mm × 26.9mm × 26.9mm)
• Standards: UL/CSA Class H compliant
• Applications: Motor protection, switchgear, industrial power distribution
• AIC rating: 10kA@250V
• Weight: 1.3 lb (0.59 kg)
• Diameter: 1.06" (26.9mm)
• Barrels: 1

Product Identification

• UPC: 051712185455
• GTIN: 00051712185455
