Bussmann MV055F2DAX400E - Medium Voltage Fuse 400A 5500V (ANSI Class E 50kA AIC)
Regular price
$0.00
$0.00
Regular price
$10,236.89
$10,236.89
Sale price
$0.00
$0.00
Save $10,236.89
/
- In stock, ready to ship
- Backordered, shipping soon
The Bussmann MV055F2DAX400E is a medium voltage current-limiting fuse designed for high-capacity circuit protection in industrial power distribution systems. It features a 5500V AC voltage rating with a 400A current rating, providing reliable overcurrent protection for medium voltage applications. The fuse employs a dual-barrel construction measuring 15.86 inches in length with a 2-inch diameter and 12-inch clip center spacing, housed in a robust design weighing 18 lb. Certified to ANSI standards with Class E rating, this fuse meets rigorous industry requirements for medium voltage protection. It is engineered for use in industrial power systems, motor control centers, and transformer protection applications where high interrupting capacity up to 50kA at 5.5kV is required.
Key Features & Specifications
Product Identification
Key Features & Specifications
- Type: Medium voltage current-limiting fuse, dual-barrel construction
- Voltage Rating: 5500V AC
- Current Rating: 400A
- Dimensions: 3" x 15.86" x 3" (Width x Height x Depth)
- Standards: ANSI certified, Class E rating
- Applications: Industrial power distribution, motor control centers, transformer protection
- AIC rating: [email protected]
- Barrels: 2
- Diameter: 2 inches
- Clip Center: 12 inches
- Weight: 18 lb
- Family: MV055
- Country of Origin: Mexico
Product Identification
- UPC: 051712552936
- GTIN: 00051712552936
