Cooper Bussmann MV055F1CAX65E - Medium Voltage Fuse 65A (5500V 50kA AIC)
Regular price
$1,042.72
$1,042.72
Regular price
$2,277.42
$2,277.42
Sale price
$1,042.72
$1,042.72
Save $1,234.70
/
- In stock, ready to ship
- Backordered, shipping soon
Cooper Bussmann MV055F1CAX65E is a medium voltage fuse designed for high-voltage circuit protection in industrial power systems. This Class E fuse features a 65A current rating and 5500V voltage rating with a [email protected] interrupting capacity for reliable overcurrent protection. The compact design measures 15.75" in height with 2" width/depth and features a single-barrel construction meeting ANSI standards. Certified for industrial applications, this fuse is commonly used in motor control centers, transformers, and medium-voltage switchgear where robust protection is required.
Key Features & Specifications
Key Features & Specifications
- Type: Medium voltage current-limiting fuse (Class E)
- Voltage Rating: 5500V AC
- Current Rating: 65A
- Dimensions: 15.75" H x 2" W x 2" D (400mm x 51mm x 51mm)
- Standards: ANSI certified
- Applications: Industrial power systems, motor protection, switchgear
- AIC rating: [email protected]
- Class Rating: E
- Barrels: 1
- Clip Center: 12"
- Weight: 5 lb (2.27 kg)
- Diameter: 1" (25.4mm)
- Country of Origin: Mexico
- UPC: 051712269568
- GTIN: 00051712269568
