Bussmann MEQ30 - Midget Fast-Acting Fuse 30A (500V, 10kA AIC)

Bussmann MEQ30 is a midget fast-acting fuse designed for overcurrent protection in low voltage electrical systems. It features a 30A current rating and 500V voltage rating with an interrupting capacity of 10kA at 500V for reliable circuit protection. The compact fuse measures 1 inch in length with a 0.406-inch square profile and weighs 1.2 lb, constructed as a single-barrel design for space-constrained applications. This Eaton MEQ Series fuse meets industrial standards for electrical protection components and is commonly used in control circuits, motor branch circuits, and industrial equipment where compact, fast-acting protection is required.

Key Features & Specifications

• Type: Midget fast-acting fuse, single barrel construction
• Voltage Rating: 500V AC/DC
• Current Rating: 30A
• Dimensions: 1" length × 0.406" height × 0.406" width
• Diameter: 0.41 inches
• Weight: 1.2 lb
• Standards: Industrial electrical protection standards
• Applications: Control circuits, motor branch circuits, industrial equipment
• AIC Rating: 10kA@500V
• Class Rating: Midget
• Barrels: 1
• Item Subcategory: Low Voltage Fuse
• Family: MEQ Series

Product Identification

• UPC: 782634786764
