Edison Fuses MEN8 - Midget Fuse 8A 250V (10kA AIC @125V)

Edison Fuses MEN8 is a low-voltage midget fuse designed for circuit protection in industrial and commercial applications. This 250V-rated fuse provides 8A current protection with a 10kA interrupting capacity at 125V, housed in a compact 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) ceramic body weighing 1.001 lb. The single-barrel MEN-series fuse meets industry standards for midget fuse applications, commonly used in control panels, transformers, and electrical distribution systems requiring reliable overcurrent protection.

Key Features & Specifications

• Type: Ceramic-bodied midget fuse with single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 8A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb
• AIC Rating: 10kA @ 125V
• Class Rating: Midget
• Barrels: 1
• Applications: Control circuits, transformers, industrial equipment

Product Identification

• UPC: 78263452080
• GTIN: 00782634520801
