Edison Fuses MEN2.8 - Midget Fuse 2.8A (250V 10kA@125V)

Edison Fuses MEN2.8 is a low-voltage midget fuse designed for circuit protection in industrial and commercial applications. It features a 250V AC/DC voltage rating and 2.8A current rating, with a compact 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) ceramic body construction and 10kA interrupting capacity at 125V. The single-barrel design meets industry standards for reliable overcurrent protection in control circuits, instrumentation, and small power distribution systems where space constraints exist.

Key Features & Specifications

• Type: Ceramic-bodied midget fuse with time-delay characteristics
• Voltage Rating: 250V AC/DC
• Current Rating: 2.8A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb
• Class Rating: Midget
• Barrels: 1
• AIC Rating: 10kA@125V
• Standards: UL/CSA recognized
• Applications: Control circuits, instrumentation, small power distribution

Product Identification

• UPC: 78263452023
• GTIN: 00782634520238
