Edison Fuses MEN1.8 - Midget Fuse 1.8A (250V 10kA AIC)

Edison Fuses MEN1.8 is a midget-class low voltage fuse designed for circuit protection in industrial and commercial applications. This 250V AC/DC-rated fuse features a 1.8A current rating with a 10kA interrupting capacity at 125V, housed in a compact cylindrical design measuring 1" length × 0.406" diameter with single-barrel construction. The fuse meets industry standards for low-voltage protection with its durable ceramic body and precision-engineered fusible element. Typical applications include control circuits, instrumentation, and small appliance protection where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: Midget fast-acting ceramic fuse
• Voltage: 250V AC/DC
• Current: 1.8A
• Dimensions: 1" L × 0.406" W × 0.406" H (25.4mm × 10.3mm × 10.3mm)
• Weight: 1.001 lb
• Diameter: 0.41" (10.4mm)
• Standards: UL/CSA recognized
• Applications: Control circuits, instrumentation, small appliances
• Class Rating: Midget
• Barrels: 1
• AIC rating: 10kA@125V

Product Identification

• UPC: 78263452018
• GTIN: 00782634520184
