Edison Fuses MCL8 - Midget Fuse 8A 600V (100kA AIC)

Edison Fuses MCL8 is a midget low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC with an 8A current capacity, it provides reliable overcurrent protection with a 100kA interrupting rating at 600V. The compact cylindrical design measures 1" x 0.406" x 0.406" (25.4mm x 10.3mm x 10.3mm) with a 0.41" (10.4mm) diameter, constructed for space-constrained applications. Compliant with industry standards for low-voltage fuses, it's commonly used in control panels, motor circuits, and power distribution equipment requiring midget-class protection.

Key Features & Specifications

• Type: Midget low-voltage fuse, single-barrel design
• Voltage Rating: 600V AC/DC
• Current Rating: 8A
• Dimensions: 1" L x 0.406" W x 0.406" H (25.4mm x 10.3mm x 10.3mm)
• Diameter: 0.41" (10.4mm)
• Weight: 1.001 lb
• AIC Rating: 100kA@600V
• Class Rating: Midget
• Barrels: 1
• Applications: Industrial control circuits, motor protection, power distribution

Product Identification

• UPC: 78263442017
• GTIN: 00782634420170
