Edison Fuses MCL4 - Midget Fuse 4A 600V (100kA AIC)

Edison Fuses MCL4 is a midget low-voltage fuse designed for circuit protection in industrial electrical systems. Rated for 600V AC/DC operation with a 4A current capacity, it provides reliable overcurrent protection with a 100kA interrupting rating at 600V. The compact cylindrical design measures 1" x 0.406" x 0.406" (LxWxH) with a 0.41" diameter, constructed to UL/CSA standards for safety compliance. This Class Midget fuse is engineered for demanding applications including motor control circuits, transformer protection, and industrial control panels where space-efficient protection is critical.

Key Features & Specifications

• Type: Midget fast-acting fuse, single barrel construction
• Voltage Rating: 600V AC/DC
• Current Rating: 4A
• Dimensions: 1" L x 0.406" W x 0.406" H
• Weight: 1.001 lb
• Diameter: 0.41"
• Standards: UL/CSA compliant
• Applications: Motor controls, transformers, industrial panels
• AIC rating: 100kA@600V
• Class Rating: Midget
• Barrels: 1

Product Identification

• UPC: 78263442014
• GTIN: 00782634420149
